DESCRIPTION
DeVilbiss Advance HD Trans-Tech pressure feed spray gun has a balanced air valve design for lighter trigger pull and improved air flow. Trans-Tech Compliant air caps provide superior finish with less over spray.
DeVilbiss Advance HD Trans-Tech pressure feed spray guns are a compliant mid sized gun designed for use with paint pressure pots and double diaphragm pumps to deliver automotive high quality finishing for industrial paint applications with less over spray.
DeVilbiss expertise and performance is unequalled in the industry!
Advance HD unrivalled high performance is achieved with new design technology utilising high capacity air passages with a separate “balanced” air valve to provide an unrestricted flow of compressed air through the gun body. This “free breathing” air movement enables the precision-engineered air caps and fluid tips to produce superior atomisation with consistent even distribution throughout the spray pattern. DeVilbiss Advance HD is precision built using the best materials and component parts for a guaranteed, reliable, long and durable working life in all industrial markets.
DeVilbiss Advance HD Pressure Feed Spray Gun – Naturally comfortable
Light weight with a lighter trigger action and increased finger room. DeVilbiss Advance HD is perfectly balanced and naturally comfortable thanks to the fit and feel of the contoured handle design. It greatly reduces operator fatigue and significantly lessens the chances of RSI or finger problems. Comfort that pays off by increasing productivity wherever DeVilbiss Advance spray guns are used, whether it’s a small finishing operation or a high volume production line.
DeVilbiss Advance HD Pressure Feed Spray Gun Features –
FEATURES:
- Balanced air valve design for lighter trigger pull and improved air flow
- Trans-Tech Compliant and HVLP air caps provide superior finish with the best possible paint savings and transfer efficiency
- Contoured handle design – Greatly reduces RSi and operator fatigue
- Stainless Steel tips, needles and fluid passageways as standard
- CE marked and fully ATEX approved.
- Robust, Lightweight and work friendly design for High Demand outputs
SPECIFICATIONS
Gun Head Weight: 495 g
Air Supply Connection: Universal 1/4″ (fits 1/4″ BSP and 1/4″ NPS male)
Air Inlet Pressure: 2 bar (29 psi)
Air Consumption: 283 l/min
Typical Fluid Flow: 160-220 ml
Typical Fan Pattern Size: 270 mm
Maximum Static Air Inlet Pressure: P1 = 12 bar (175 psi)
Maximum Static Fluid Inlet Pressure: P2 = 14 bar (203 psi)
Fluid Supply Connection: Universal 3/8″ (fits 3/8″ BSP and 3/8″ NPS male)
Service Temperature: 0 to 40°C
Suitable for: Waterbased & Solvent based coating materials
