DISPOSABLE CONCERTINA FILTER

DESCRIPTION
Standard Filters are used in the exhaust of paint booths for over-spray collection. The front V-shaped wall prevents over-spray bounce back and migration. The deeper V-shape of the back wall is the paint holding pocket. The exhaust holes are misaligned to divert the paint laden airflow to the holding pocket, where the paint is captured, while maintaining a constant flow during the loading phase.

FEATURES:

• Lasts 3 x 5 times longer than poly, fiberglass or mesh media
• Captures any wet solid or liquid particles
• Standard & high efficiency options
• V shape wall prevents over spray and bounce back migration
• Easy to cut, replace and install
• Static pressure increases slowly with the accumulation of over spray resulting in uniform airflow.
• Made out of 2 layers of heavy “Kraft” paper, punched, pleated and glued together with 2 built-in extension limiters. Thanks to these limiters, the maximum load capacity is guaranteed.

AVAILABLE IN:
90cm – 90cm x 9m
100cm – 100cm x 10m
