CAR BUILDERS MASS NOISE LINER

SKU: MNL-AAAA

DESCRIPTION
Car Builders Mass Noise Liner is a 12mm thick, heavy weight barrier as used in high end luxury vehicles. It is the most effective sound proofing material on the market.
Construction
2mm Mass Loaded vinyl upper layer, coupled with an 10mm closed cell foam to create the most effective means of acoustic blocking. Our flexible closed cell foam is water resistant and offers superior thermal insulation.

FEATURES:

  • Heavy duty sound blocking
  • Water resistant
  • Removable
  • Cuts with scissor and knife
  • Reduces heat transfer
  • Does not rot or deteriorate

APPLICATIONS:

  • Firewalls
  • Cargo areas
  • Van floors
  • Boot floors
  • It is not 100% necessary to put Stage 1 Sound Deadener underneath Mass Noise Liner on cargo area floors or van floors due to the metal already being fairly rigid from the ribs. The Mass Noise Liner will be an effective floor sound proofing by itself.

USED FOR:
4WD’s and muscle cars – firewall barrier to reduce engine noise
Trucks – reduce engine noise and heat on floors and firewalls, great for serviceability
Exhaust drone – drop in as a boot liner to reduce exhaust drone particular common in 6’s, V8’s and flat fours.
Engine rooms, compressors etc

Note: due to the weight of our Mass Noise Liner it is not recommended for use on the underside of horizontal surfaces. For these applications you should use our light weight foam such as Acoustic Liner, Water proof carpet underlay, Under bonnet insulation or our 6mm Insul-layer.

SPECIFICATIONS
Sheet length: 1600MM
Sheet width: 950MM
Sheet thickness: 12MM (2MMVINYL, 10MM FOAM)
Weight: 4.5KG / SQM
“Temperature resistance: 130°C”
“Flammability: UL94 V0″
“Foam flame retardant: Grade B2″

Specifications

BRANDS

CAR BUILDERS

BODY REPAIR & RESTORATION

SOUND & HEAT DEADENING

SIZE

1500 X 950MM, 1500 X 1000M

HOW TO USE VIDEO
